Nature Mini PRO (Thermostat)

ControlPanel

Super Panel PRO (Thermostat) is a 2-in-1 fresh air and floor heating control panel featuring a 4-inch IPS high-definition color display. It allows multi-touch control of various home temperature settings and smart devices.

Six Operating Modes

Supports various heating and ventilation combinations

Smart Temperature Control

Adjusts whole-home climate with temperature and humidity sensors

Energy-Saving Control

Timed switches and smart temperature reduce electricity bills

Remote Comfort Control

Adjust switches, temperature, and modes for family safety

Specifications

Model Number

LS268-WT1/GT1

Installation

In-wall concealed with 86 back box

Operating Temperature

-5~45℃

Operating Humidity

5~90%

Network

Wi-Fi 2.4GHz/5GHz

Interface

Low, Med, High, Val1, Val2, Live, Neutral

Screen

4 inch

Resolution

480*480

Operation System

Linux

Power Supply

AC 100-240V 50/60Hz

Speaker

Yes

Color

White/Gray

Dimension

Outside the wall: 86*86*11mm
Whole product: 86*86*36mm

Casing

Flameresistant PC

Net Weight

156.8g(1 way) / 165.3g(2 way) / 173.9g(3 way)

Gross Weight

226.1g(1 way) / 234.2g(2 way) / 242.8g(3 way)

Radio Protocol

CoSS, ZigBee, Wi-Fi

Signal Range(Open Field)

200m

Controllable Devices

Switches, lights, curtain motors, tubular motors, underfloor thermostats, fan coil thermostat, air conditioner gateways, electrical appliances(via SPOT-universal infrared controllers), etc.
