Polar Switch

Flexible Wiring, Flicker-Free Control

Smart SwitchSingle Live
Pollar Switch features ultra-low power consumption and an independent power supply, supporting single live, neutral and live, and low DC (≤30V). Optional live-only wiring installs without rewiring and eliminates flicker with low-power bulbs for easy use.
Flicker-Free Stability
No flicker, safe and stable performance
Flexible Control
From dual to multi-way with ease
Easy Installation
No extra wiring or screw-free

Specifications
for Single Live Version

Product
Polar Switch (Single Live)
Wiring
Live Only
Radio Protocol
CoSS
Signal Range
200m (open field)
Way
1/2/3 ways for choice
Weight
1 way-103g, 2 ways-112g, 3 ways-123g
Dimension
120*70*35mm
Casing
ABS+PC
Control Unit
16A magnetic latching relay
Operating Temperature
-5~45℃
Operating Humidity
5~90％
Power Supply
DC 5V-30V Or AC 90-250V
Static Consumption
＜1mW
Maximum Overload
Resistive load 500W (one way), Capacitive/Reductive load 200W (one way)
Battery Type
CR123A
Battery Lfie
5 years

Specifications
for Live & Neutral Version

Product
Polar Switch (Live & Neutral)
Wiring
Live+Neutral
Ways
1/2/3 ways
Weight
1way-121g, 2 ways-127g, 3 ways-133g
Radio Protocol
CoSS
Signal Range
200m (open field)
Dimension
120*70*35mm
Casing
Bottom Cover:PC, Top Cover:ABS+PC
Control Unit
16A magnetic latching relay
Operating Temperature
-5~45℃
Operating Humidity
5~90％
Power Supply
AC 100-240V 50/60Hz
Static Consumption
＜0.6W
Maximum Overload
Resistive load 500W (one way）Capacitive/Reductive load 200W (one way)
